Download N98PBL Specification
What's in the Box
➀ 1X NVR➁ 1X USB Mouse➂ 1X Power Adapter➃ 1X 1 m Network Cable➄ 1X 1.8 m HDMI Cable➅ 1X User Manual
Video & Audio
| Video CompressionH.265+/H.265/H.264+/H.264 |
IP Video Input8CH PoE |
| Video OutputHDMI & VGA up to 1080p |
Incoming Bandwidth60 M |
| Max Recording ResolutionUp to 6MP |
Max Playback ResolutionUp to 6MP |
| Max Playback Channel8CH |
Max Playback Capacity4CH@1080p, 1CH@6MP |
| Video CompressionH.265+/H.265/H.264+/H.264 |
| Video OutputHDMI & VGA up to 1080p |
| Max Recording ResolutionUp to 6MP |
| Max Playback Channel8CH |
| IP Video Input 8CH PoE |
| Incoming Bandwidth 60 M |
| Max Playback Resolution Up to 6MP |
| Max Playback Capacity 4CH@1080p, 1CH@6MP |
Hard Drive
| HDD1 SATA Interface |
HDD CapacityUp to 6 TB Capacity |
| HDD1 SATA Interface |
| HDD Capacity Up to 6 TB Capacity |
External Interface
| Network InterfaceRJ45 X1 (10/100 M) |
PoE8 Ports (IEEE802.3at/af) |
| USB2X USB 2.0 |
|
| Network InterfaceRJ45 X1 (10/100 M) |
| USB2X USB 2.0 |
| PoE 8 Ports (IEEE802.3at/af) |
General
| Operating PowerDC 48 V |
Working Temperature14 °F - 131 °F/-10 °C - +55 °C |
| Dimensions (W X H X D)10.4" X 8.9" X 1.9"/265 X 225 X 48 mm |
Weight (Without Hard Disk)2.2 lbs./1 kg |
Power Consumption≤10 W (Without HDD and PoE)
PoE: Max 25.5 W for Single Port |
|
| Operating PowerDC 48 V |
| Dimensions (W X H X D)10.4" X 8.9" X 1.9"/265 X 225 X 48 mm |
Power Consumption≤10 W (Without HDD and PoE)
PoE: Max 25.5 W for Single Port |
| Working Temperature 14 °F - 131 °F/-10 °C - +55 °C |
| Weight (Without Hard Disk) 2.2 lbs./1 kg |
