| Decoding FormatH.264/H.264+/H.265/H.265+ |
IP Video Input16CH PoE |
| Audio Input/Output1/1 RCA |
Incoming/outgoing Bandwidth16CH PoE |
| Max Playback ResolutionUp to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) |
Max Playback Channel16CH |
| Video OutputHDMI up to 4K (3840 × 2160), VGA up to 1080p(1920 × 1080), independent output |
Max Recording ResolutionUp to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) |
| Motion Detection 2.0 by IP camera16-ch (Need IP camera support motion 2.0) |
Motion Detection 2.0 by NVR16-ch (IP camera does not need to support motion 2.0) |
Max Playback CapacityAI on: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)
AI off: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps) |
Smart Event by IP camera16-ch line crossing detection, intrusion detection, region entrance detection, region exiting
detection,facial recognition,throwing objects from building, ANPR, VCA(Need IP camera support) |
| Facial Detection and Analytics2-ch line crossing detection, intrusion detection, region entrance detection, region exiting detection (IP camera does not need to support these function but the resolution cannot exceed 4MP) |
Face Picture LibraryUp to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4
MB, total capacity ≤ 1 GB) |
| Facial Detection and Analytics1-ch, 8 MP,Face picture comparison, human face capture, face picture search |
NoteFacial recognition, motion detection 2.0 or perimeter protection cannot be enabled at the same time. |
| Face Picture Comparison4-ch |
IP Video Input2 SATA Interface |
| HDD CapacityUp to 10 TB capacity for each HDD |
Alarm In/Out4/1 |
| Network Interface1, RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
PoE16, RJ-45 10/100 Mbps self-adaptive Ethernet interface, IEEE 802.3 af/at |
| USB interfaceUSB 2.0*2 |
|
| Decoding FormatH.264/H.264+/H.265/H.265+ |
| Audio Input/Output1/1 RCA |
| Max Playback ResolutionUp to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) |
| Video OutputHDMI up to 4K (3840 × 2160), VGA up to 1080p(1920 × 1080), independent output |
| Motion Detection 2.0 by IP camera16-ch (Need IP camera support motion 2.0) |
Max Playback CapacityAI on: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)
AI off: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps) |
| Facial Detection and Analytics2-ch line crossing detection, intrusion detection, region entrance detection, region exiting detection (IP camera does not need to support these function but the resolution cannot exceed 4MP) |
| Facial Detection and Analytics1-ch, 8 MP,Face picture comparison, human face capture, face picture search |
| Face Picture Comparison4-ch |
| HDD CapacityUp to 10 TB capacity for each HDD |
| Network Interface1, RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
| USB interfaceUSB 2.0*2 |
| IP Video Input
16CH PoE |
| Incoming/outgoing Bandwidth
16CH PoE |
| Max Playback Channel
16CH |
| Max Recording Resolution
Up to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) |
| Motion Detection 2.0 by NVR
16-ch (IP camera does not need to support motion 2.0) |
Smart Event by IP camera
16-ch line crossing detection, intrusion detection, region entrance detection, region exiting
detection,facial recognition,throwing objects from building, ANPR, VCA(Need IP camera support) |
Face Picture Library
Up to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4
MB, total capacity ≤ 1 GB) |
| Note
Facial recognition, motion detection 2.0 or perimeter protection cannot be enabled at the same time. |
| IP Video Input
2 SATA Interface |
| Alarm In/Out
4/1 |
| PoE
16, RJ-45 10/100 Mbps self-adaptive Ethernet interface, IEEE 802.3 af/at |
