4K 128 Channel 2U Non-PoE NVR Recorder

4K 128 Channel 2U Non-PoE NVR Recorder

$4,799.99 MSRP
Model Number: N84SBM
  • Up to 128 channel IP cameras can be connected.
  • Video outputs at up to 4K (4096×2160) resolution.
  • Up to 576 Mbps high incoming bandwidth ensures IP cameras can be connected.
  • 2 HDMI (different source) and 1 VGA interfaces16 HDD can be used for continuous video recording.
  • 16 HDD can be used for continuous video recording.
  • Supports some specialist cameras, including people counting camera/ANPR (automatic number plate recognition) camera/fisheye camera.
  • Advanced streaming technology enables smooth live view in poor network conditions.
  • Supports RAID 0, 1, 5, 6, 10 and N+1 hot spare for even more reliable data storage, effectively avoids data loss risks.
    • Contact Sales

    ANNKE brand or unbranded options

    Flexible MOQ & bulk order discounts

    Ready stock for fast delivery

    Reliable after‑sales & technical support

    Specification

    Download N84SBM Specification

    N84SBM NVR
    Incoming Bandwidth576 Mbps Outgoing Bandwidth (RAID Mode)512 Mbps
    TLS Outgoing Bandwidth128 Mbps, or 64 Mbps (when RAID is enabled) LCD OutputOptional: One 7 inch LCD
    Audio Output1-ch. RCA (2.0 Vp-p, 1 KΩ) Two-Way Audio1-ch. RCA (2.0 Vp-p, 1 KΩ)
    HDMI OutputTwo independent HDMI outputs of 4K resolution. Resolution: 4K (4096 × 2160), 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1080p (1920 × 1080)/60Hz, UXGA (1600 × 1200)/60Hz, SXGA (1280 × 1024)/60Hz, 720p (1280 × 720)/60Hz, XGA (1024 × 768)/60Hz VGA Output1-ch. Resolution: 1080p (1920 × 1080)/60Hz, UXGA (1600 × 1200)/60Hz, SXGA (1280 × 1024)/60Hz, 720p (1280 × 720)/60Hz, XGA (1024 × 768)/60Hz
    Decoding FormatH.265, H.265+, H.264, H.264+,MPEG4, MJPEG (for Hikvision IP camera only) Synchronous PlaybackUp to 16 channels
    Recording Resolution32 MP/24 MP/12 MP/8 MP/7 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p /VGA/4CIF/DCIF/2CIF/CIF/QCIF
    *: 32 MP and 24 MP is only available for channel 1 to 4 when ultra HD resolution mode is enabled.    		 Decoding Capability1-ch@32 MP (8160 × 3616, 30 fps)/5-ch@8 MP(30 fps)/10-ch@4 MP(30 fps)/20-ch@1080p(30 fps)/40-ch@720p(30 fps)
    *: The length or width of camera resolution (each track) cannot exceed 4096 pixels.
    Network ProtocolIPv6, HTTPS, UPnP, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, DDNS Network Interface4, RJ45 10M/100M/1000M self-adaptive Ethernet interface
    Interface16 SATA interfaces supporting hot-plug RAID TypeRAID0, RAID1, RAID5, RAID 6, and RAID10
    Camera Access ProtocolHIKVISION, ACTi, ARECONT, AXIS, BOSCH, BRICKCOM, CANON, HUNT, ONVIF (Version 2.5), PANASONIC, PELCO, RTSP, SAMSUNG, SONY, VIVOTEK, ZAVIO SATA2 × mini SAS interface (optional)
    ESATA1 × eSATA interface CapacityUp to 10 TB for each HDD
    Serial InterfaceRS-232; RS-485; Keyboard USB InterfaceFront Panel: 2 × USB 2.0; Rear Panel: 2 × USB 3.0
    Alarm In/Out16/8 Power Supply100 to 240 VAC, 50 to 60Hz, 5 A
    Extension BoardOne extension board is supported with four 10M/100M/1000M optical interfaces (1.25 Gbps SFP module), eight RS-485 interfaces, and alarm interface of 32 alarm inputs and 16 alarm outputs. Consumption≤ 140W
    Working Temperature0 °C to + 50 °C (32 °F to 122 °F) Working Humidity10% to 90%
    Dimension (W × D × H)442 × 494 × 146 mm (17.4 × 19.4 × 5.7 inch) Weight≤ 16 kg (35.3 lb)
    Incoming Bandwidth576 Mbps
    Outgoing Bandwidth (RAID Mode)512 Mbps
    TLS Outgoing Bandwidth128 Mbps, or 64 Mbps (when RAID is enabled)
    LCD OutputOptional: One 7 inch LCD
    Audio Output1-ch. RCA (2.0 Vp-p, 1 KΩ)
    Two-Way Audio1-ch. RCA (2.0 Vp-p, 1 KΩ)
    HDMI OutputTwo independent HDMI outputs of 4K resolution. Resolution: 4K (4096 × 2160), 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1080p (1920 × 1080)/60Hz, UXGA (1600 × 1200)/60Hz, SXGA (1280 × 1024)/60Hz, 720p (1280 × 720)/60Hz, XGA (1024 × 768)/60Hz
    VGA Output1-ch. Resolution: 1080p (1920 × 1080)/60Hz, UXGA (1600 × 1200)/60Hz, SXGA (1280 × 1024)/60Hz, 720p (1280 × 720)/60Hz, XGA (1024 × 768)/60Hz
    Decoding FormatH.265, H.265+, H.264, H.264+,MPEG4, MJPEG (for Hikvision IP camera only)
    Synchronous PlaybackUp to 16 channels
    Recording Resolution32 MP/24 MP/12 MP/8 MP/7 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p /VGA/4CIF/DCIF/2CIF/CIF/QCIF
    *: 32 MP and 24 MP is only available for channel 1 to 4 when ultra HD resolution mode is enabled.
    Decoding Capability1-ch@32 MP (8160 × 3616, 30 fps)/5-ch@8 MP(30 fps)/10-ch@4 MP(30 fps)/20-ch@1080p(30 fps)/40-ch@720p(30 fps)
    *: The length or width of camera resolution (each track) cannot exceed 4096 pixels.
    Network ProtocolIPv6, HTTPS, UPnP, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, DDNS
    Network Interface4, RJ45 10M/100M/1000M self-adaptive Ethernet interface
    Interface16 SATA interfaces supporting hot-plug
    RAID TypeRAID0, RAID1, RAID5, RAID 6, and RAID10
    Camera Access ProtocolHIKVISION, ACTi, ARECONT, AXIS, BOSCH, BRICKCOM, CANON, HUNT, ONVIF (Version 2.5), PANASONIC, PELCO, RTSP, SAMSUNG, SONY, VIVOTEK, ZAVIO
    SATA2 × mini SAS interface (optional)
    ESATA1 × eSATA interface
    CapacityUp to 10 TB for each HDD
    Serial InterfaceRS-232; RS-485; Keyboard
    USB InterfaceFront Panel: 2 × USB 2.0; Rear Panel: 2 × USB 3.0
    Alarm In/Out16/8
    Power Supply100 to 240 VAC, 50 to 60Hz, 5 A
    Extension BoardOne extension board is supported with four 10M/100M/1000M optical interfaces (1.25 Gbps SFP module), eight RS-485 interfaces, and alarm interface of 32 alarm inputs and 16 alarm outputs.
    Consumption≤ 140W
    Working Temperature0 °C to + 50 °C (32 °F to 122 °F)
    Working Humidity10% to 90%
    Dimension (W × D × H)442 × 494 × 146 mm (17.4 × 19.4 × 5.7 inch)
    Weight≤ 16 kg (35.3 lb)
