Download I51DL Specification
What's in the Box
➀ 1X Security Camera(s)
➁ 1X Mounting Screw Bag(s)
➂ 1X User Manual
Camera
|
Image Sensor1/3" Progressive Scan CMOS |
Video CompressionH.265+/H.265/H.264+/H.264 |
Main Stream Max. Frame Rate50 Hz: 20 fps (2592 X 1944), 25 fps (2560 X 1440, 2304 X 1296, 1920 X 1080, 1280 X 720)
60 Hz: 20 fps (2592 X 1944), 30 fps (2560 X 1440, 2304 X 1296, 1920 X 1080, 1280 X 720) |
Substream Max. Frame Rate50 Hz: 25 fps (640 X 480, 640 X 360, 320 X 240)
60 Hz: 30 fps (640 X 480, 640 X 360, 320 X 240) |
|
Video Bitrate32 Kbps - 8 Mbps |
Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
|
Audio InputBuilt-in Microphone |
Min. IlluminationColor: 0.028 Lux @(F2.0, AGC On) |
|
Angle of ViewHorizontal FoV 71.5°, Vertical FoV 53°, Diagonal FoV 91° |
Number of Infrared LEDs2 pcs |
|
Night Vision DistanceUp to 100 ft/30 m |
DNR3D DNR |
|
Wide Dynamic Range120 dB WDR |
ONVIFSupport |
|
IR-Cut FilterYes |
EthernetRJ45 X1 (10 M/100 M) |
|
Image Sensor1/3" Progressive Scan CMOS |
Main Stream Max. Frame Rate50 Hz: 20 fps (2592 X 1944), 25 fps (2560 X 1440, 2304 X 1296, 1920 X 1080, 1280 X 720)
60 Hz: 20 fps (2592 X 1944), 30 fps (2560 X 1440, 2304 X 1296, 1920 X 1080, 1280 X 720) |
|
Video Bitrate32 Kbps - 8 Mbps |
|
Audio InputBuilt-in Microphone |
|
Angle of ViewHorizontal FoV 71.5°, Vertical FoV 53°, Diagonal FoV 91° |
|
Night Vision DistanceUp to 100 ft/30 m |
|
Wide Dynamic Range120 dB WDR |
|
IR-Cut FilterYes |
|
Video Compression H.265+/H.265/H.264+/H.264 |
Substream Max. Frame Rate 50 Hz: 25 fps (640 X 480, 640 X 360, 320 X 240)
60 Hz: 30 fps (640 X 480, 640 X 360, 320 X 240) |
|
Audio Compression G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
|
Min. Illumination Color: 0.028 Lux @(F2.0, AGC On) |
|
Number of Infrared LEDs 2 pcs |
|
DNR 3D DNR |
|
ONVIF Support |
|
Ethernet RJ45 X1 (10 M/100 M) |
General
|
HousingMetal & Plastic |
ColorWhite |
|
StorageBuilt-in microSD/SDHC/SDXC Slot, up to 256 GB |
Hardware ResetYes |
|
Operating PowerDC 12 V; PoE (802.3af) |
Operating Temperature-22 °F – 140 °F/-30 °C – 60 °C |
|
Indoor/Outdoor UseIndoor/Outdoor |
Interface ProtectionIP67, TVS 2000 V Lightning Protection, Surge Protection and Voltage Transient Protection |
|
Dimension (L X W X H)7.0" X 2.6" X 2.7"/177.6 X 66.2 X 67.8 mm |
Weight0.6 lb./270 g |
|
HousingMetal & Plastic |
|
StorageBuilt-in microSD/SDHC/SDXC Slot, up to 256 GB |
|
Operating PowerDC 12 V; PoE (802.3af) |
|
Indoor/Outdoor UseIndoor/Outdoor |
|
Dimension (L X W X H)7.0" X 2.6" X 2.7"/177.6 X 66.2 X 67.8 mm |
|
Color White |
|
Hardware Reset Yes |
|
HOperating Temperature -22 °F – 140 °F/-30 °C – 60 °C |
|
Interface Protection IP67, TVS 2000 V Lightning Protection, Surge Protection and Voltage Transient Protection |
|
Weight 0.6 lb./270 g |
